The Inclined Screw Thickener is an essential piece of equipment in the pulp and paper industry, designed to thicken and wash different types of pulp. It features a special screw and a self-cleaning filter drum that ensures high filtration efficiency and minimizes downtime. This machine is adaptable to varying pulp types and consistency ranges, with an adjustable filter drum hole diameter to optimize fiber retention and reduce material loss. The pulp level in the tank can be easily controlled, allowing for precise discharge consistency.
Main Technical Parameters
|
Type |
ZNX1 |
ZNX2 |
ZNX3 |
ZNX8 |
ZNX9 |
ZNX12 |
|
|
Nominal filtrating area: ㎡ |
1×1 |
1×2 |
1×3 |
1.5×2 |
1.5×3 |
2×3 |
|
|
Consistency of inflow pulp: % |
3×4 |
||||||
|
Consistency of outflow pulp: % |
10×14 |
||||||
|
Capacity of Production: t/d |
OCC |
18～23 |
35～45 |
50～70 |
50～70 |
80～100 |
100～130 |
|
ONP |
10～15 |
20～30 |
30～45 |
30～45 |
50～60 |
60～80 |
|
|
Power of motor: kw |
4 |
4×2 |
4×3 |
7.5×2 |
7.5×3 |
11×3 |
|
|
(L×W×H): mm |
2000×600×2725 |
2000×865×2725 |
2000×1280×2725 |
2300×1100×3400 |
2300×1550×3400 |
2350×1800×3750 |
|
Advantage of Inclined Screw Thickenner
High Filtration Efficiency
The self-cleaning filter drum ensures reliable operation with minimal maintenance.
Flexible Operation
Adjustable filter drum holes accommodate different pulp types and consistency levels, reducing fiber loss.
Consistent Discharge
The pulp level in the tank can be controlled, offering precise management of discharge consistency.
Improved Fiber Retention
Designed to minimize fiber loss during the thickening and washing processes.
Durable and Low Maintenance
The robust screw and self-cleaning filter drum ensure long-term, efficient performance.
Versatile Application
Suitable for a wide range of pulp types and used across various stages of paper pulp processing.
Function & application
It is used for thickening and washing in low consistency and medium consistency rang of waste paper pulping process and it is also suitable for thickening and washing pulp such as sulfate wood pulp, mechanical pulp, and chemi-mechanical pulp, etc.
Main components
The inclined spiral concentrating unit is mainly composed of a feed taper pipe, a base, a box body, a spiral main shaft, a filter tube, a cover plate, a reduction box and a motor.
